Neo4j
Neo4j 是一款面向关系数据建模的图数据库。本文将从基础概念出发，介绍 Neo4j 的常见用法，包括节点、关系、属性的建模方式，Cypher 查询语句的基本写法，以及如何进行数据创建、查询、更新和关系路径分析，帮助你快速理解图数据库的使用场景和开发流程。
1.查询
1.1按属性筛选
MATCH (p:Person {name: 'Tom Hanks'})
RETURN p
1.2返回属性值
MATCH (p:Person {name: 'Tom Hanks'})
RETURN p.born
1.3使用where语句筛选
MATCH (p:Person)
WHERE p.name = 'Tom Hanks' OR p.name = 'Rita Wilson'
RETURN p.name, p.born
不等于判断：
MATCH (p:Person)-[:ACTED_IN]->(m:Movie)
WHERE p.name <> 'Tom Hanks' // p的名称不等于Tom Hanks的人
AND m.title = 'Captain Phillips'
RETURN p.name
1.4关系查找
MATCH (p:Person {name: 'Tom Hanks'})-[:ACTED_IN]->(m:Movie)
WHERE m.title='The Matrix'
RETURN m.title
注：如果不提供其中的Movie标签 则查找所有类型的m
另一种写法：
MATCH (p)-[:ACTED_IN]->(m)
WHERE p:Person AND m:Movie AND m.title='The Matrix'
RETURN p.name
1.4.1范围查询
MATCH (p:Person)-[:ACTED_IN]->(m:Movie)
WHERE 2000 <= m.released <= 2003
RETURN p.name, m.title, m.released
MATCH (m:Movie) WHERE m.title = 'Toy Story'
RETURN
m.year < 1995 AS lessThan, // Less than (false)
m.year <= 1995 AS lessThanOrEqual, // Less than or equal(true)
m.year > 1995 AS moreThan, // More than (false)
m.year >= 1995 AS moreThanOrEqual // More than or equal (true)
1.4.2判断属性存在
IS NOT NULL
MATCH (p:Person)-[:ACTED_IN]->(m:Movie)
WHERE p.name='Jack Nicholson' AND m.tagline IS NOT NULL
RETURN m.title, m.tagline
1.4.3子串过滤
STARTS WITH
ENDS WITH
CONTAINS
MATCH (p:Person)-[:ACTED_IN]->()
WHERE p.name STARTS WITH 'Michael'
RETURN p.name
忽略大小写：
toLower()
toUpper()
MATCH (p:Person)-[:ACTED_IN]->()
WHERE toLower(p.name) STARTS WITH 'michael'
RETURN p.name
注：这个操作将可能导致不走索引！
1.4.4关系过滤
NOT exists(xxx)
MATCH (p:Person)-[:WROTE]->(m:Movie)
WHERE NOT exists( (p)-[:DIRECTED]->(m) )
RETURN p.name, m.title
注：能用模式匹配就不要用 exists，因为性能pattern MATCH > exists
1.4.5列表筛选
IN
提供外部列表：
MATCH (p:Person)
WHERE p.born IN [1965, 1970, 1975]
RETURN p.name, p.born
属性本身是列表：
MATCH (p:Person)-[r:ACTED_IN]->(m:Movie)
WHERE 'Neo' IN r.roles AND m.title='The Matrix'
RETURN p.name, r.roles
1.4.6 OPTIONAL匹配
MATCH (m:Movie) WHERE m.title = "Kiss Me Deadly"
MATCH (m)-[:IN_GENRE]->(g:Genre)<-[:IN_GENRE]-(rec:Movie)
OPTIONAL MATCH (m)<-[:ACTED_IN]-(a:Actor)-[:ACTED_IN]->(rec)
RETURN rec.title, a.name
OPTIONAL MATCH不匹配不会影响返回结果中不存在该项，只是这里不匹配的a.name返回的是null,也就是说 会保留所有同类型电影而他们不一定有共同参演的演员
1.5查看节点/图属性
查看节点有哪些属性：
MATCH (p:Person)
RETURN p.name, keys(p)
查看图所有属性：
CALL db.propertyKeys()
1.6使用as给返回值取别名
MATCH (p:Person)
RETURN p.name AS Name
1.7使用PROFILE查询性能
PROFILE MATCH (p:Person)
RETURN p.name AS Name
1.8查看数据模型
这将展示不同标签节点之间存在什么关系:
CALL db.schema.visualization()
查询所有节点有哪些属性类型：
CALL db.schema.nodeTypeProperties()
查询所有关系有哪些属性类型：
CALL db.schema.relTypeProperties()
查看所有约束：
SHOW CONSTRAINTS
1.9对查询结果进行排序
ORDER BY
MATCH (u:User)-[r:RATED]->(m:Movie)
WHERE u.name = 'Sandy Jones'
RETURN m.title AS movie, r.rating AS rating ORDER BY r.rating DESC
ORDER BY支持多个条件排序，使用，隔开
1.10限制返回的结果数量
LIMIT
MATCH (m:Movie)
WHERE m.released IS NOT NULL
RETURN m.title AS title,
m.released AS releaseDate
ORDER BY m.released DESC LIMIT 100
1.11分页
通过skip和limit组合进行分页处理
MATCH (p:Person)
WHERE p.born.year = 1980
RETURN p.name as name,
p.born AS birthDate
ORDER BY p.born SKIP 40 LIMIT 10
1.12相同返回值去重
MATCH (p:Person)-[:DIRECTED | ACTED_IN]->(m:Movie)
WHERE p.name = 'Tom Hanks'
RETURN DISTINCT m.title, m.released
ORDER BY m.title
1.13Map投影(把节点转成JSON对象)
把整个节点的属性映射为一个person对象：
MATCH (p:Person)
WHERE p.name CONTAINS "Thomas"
RETURN p { .* } AS person
ORDER BY p.name ASC
自定义对象：
MATCH (p:Person)
WHERE p.name CONTAINS "Thomas"
RETURN p { .name, .born } AS person
ORDER BY p.name
1.14修改返回的结果
计算年龄：
MATCH (m:Movie)<-[:ACTED_IN]-(p:Person)
WHERE m.title CONTAINS 'Toy Story' AND
p.died IS NULL
RETURN m.title AS movie,
p.name AS actor,
p.born AS dob,
date().year - p.born.year AS ageThisYear
条件判断返回：
MATCH (m:Movie)<-[:ACTED_IN]-(p:Person)
WHERE p.name = 'Henry Fonda'
RETURN m.title AS movie,
CASE
WHEN m.year < 1940 THEN 'oldies'
WHEN 1940 <= m.year < 1950 THEN 'forties'
WHEN 1950 <= m.year < 1960 THEN 'fifties'
WHEN 1960 <= m.year < 1970 THEN 'sixties'
WHEN 1970 <= m.year < 1980 THEN 'seventies'
WHEN 1980 <= m.year < 1990 THEN 'eighties'
WHEN 1990 <= m.year < 2000 THEN 'nineties'
ELSE 'two-thousands'
END
AS timeFrame
1.15聚合查询
RETURN 中只要有聚合函数，就会按“非聚合字段”自动分组
1.15.1分组聚合
按照a.name, d.name相同为一组，计算其count并进行排序：
MATCH (a:Person)-[:ACTED_IN]->(m:Movie)<-[:DIRECTED]-(d:Person)
RETURN a.name, d.name,
count(*) AS numMovies
ORDER BY numMovies DESC
1.15.2列表聚合
对于每个演员，返回其演的所有电影数及一个电影列表：
MATCH (a:Person)-[:ACTED_IN]->(m:Movie)
RETURN a.name AS actor,
count(*) AS total,
collect(m.title) AS movies
ORDER BY total DESC LIMIT 10
消除列表重复项：
MATCH (a:Person)-[:ACTED_IN]->(m:Movie)
WHERE m.year = 1920
RETURN collect( DISTINCT m.title) AS movies,
collect( a.name) AS actors
返回第一个演员：
MATCH (a:Person)-[:ACTED_IN]->(m:Movie)
RETURN m.title AS movie,
collect(a.name)[0] AS castMember,
size(collect(a.name)) as castSize
返回第二个及之后的所有演员：
MATCH (a:Person)-[:ACTED_IN]->(m:Movie)
RETURN m.title AS movie,
collect(a.name)[2..] AS castMember,
size(collect(a.name)) as castSize
1.16日期时间处理
date: "2026-02-22"
datetime: "2026-02-22T12:29:41.254000000Z"
time: "12:29:41.254000000Z"
MERGE (x:Test {id: 1})
SET x.date = date(),
x.datetime = datetime(),
x.time = time()
RETURN x
访问date或datetime中的部分：
MATCH (x:Test {id: 1})
RETURN x.date.day, x.date.year,
x.datetime.year, x.datetime.hour,
x.datetime.minute
使用字符串来设置：
MATCH (x:Test {id: 1})
SET x.date1 = date('2022-01-01'),
x.date2 = date('2022-01-15')
RETURN x
MATCH (x:Test {id: 1})
SET x.datetime1 = datetime('2022-01-04T10:05:20'),
x.datetime2 = datetime('2022-04-09T18:33:05')
RETURN x
返回两个时间之间持续时间：
MATCH (x:Test {id: 1})
RETURN duration.between(x.date1,x.date2)
返回间隔天数：
MATCH (x:Test {id: 1})
RETURN duration.inDays(x.datetime1,x.datetime2).days
返回加6个月的date:
MATCH (x:Test {id: 1})
RETURN x.date1 + duration({months: 6})
使用apoc格式化时间：
MATCH (x:Test {id: 1})
RETURN x.datetime as Datetime,
apoc.temporal.format( x.datetime, 'HH:mm:ss.SSSS')
AS formattedDateTime
格式化为标准ISO8601:
MATCH (x:Test {id: 1})
RETURN apoc.date.toISO8601(x.datetime.epochMillis, "ms")
AS iso8601
1.17图遍历
1.17.1最短路径
shortestPath
找到任意关系连接下最短路径：
MATCH p = shortestPath((p1:Person)-[*]-(p2:Person))
WHERE p1.name = "Eminem"
AND p2.name = "Charlton Heston"
RETURN p
找到仅存在ACTED_IN关系（不区分方向）的最短路径：
MATCH p = shortestPath((p1:Person)-[:ACTED_IN*]-(p2:Person))
WHERE p1.name = "Eminem"
AND p2.name = "Charlton Heston"
RETURN p
找到相距两跳的节点：
MATCH (p:Person {name: 'Eminem'})-[:ACTED_IN*2]-(others:Person)
RETURN others.name
找到最多4条的节点：
MATCH (p:Person {name: 'Eminem'})-[:ACTED_IN*1..4]-(others:Person)
RETURN others.name
1.18管道查询
1.18.1作用域变量
WITH 'toy story' AS mt, 'Tom Hanks' AS actorName
MATCH (p:Person)-[:ACTED_IN]->(m:Movie)
WITH m, toLower(m.title) AS movieTitle
WHERE p.name = actorName
AND movieTitle CONTAINS mt
RETURN m.title AS movies, movieTitle
注：WITH和WHERE处于同一阶段，所有这里可以访问p,但是return中访问不了p,mt,actorName
使用with限制返回数：
WITH 'Tom Hanks' AS theActor
MATCH (p:Person)-[:ACTED_IN]->(m:Movie)
WHERE p.name = theActor
WITH m LIMIT 2
// possibly do more with the two m nodes
RETURN m.title AS movies
使用with排序：
WITH 'Tom Hanks' AS theActor
MATCH (p:Person)-[:ACTED_IN]->(m:Movie)
WHERE p.name = theActor
WITH m ORDER BY m.year LIMIT 5
// possibly do more with the five m nodes in a particular order
RETURN m.title AS movies, m.year AS yearReleased
在with中使用映射，指定要返回的字段：
MATCH (n:Movie)
WHERE n.imdbRating IS NOT NULL
AND n.poster IS NOT NULL
WITH n {
.title,
.year,
.languages,
.plot,
.poster,
.imdbRating,
directors: [ (n)<-[:DIRECTED]-(d) | d { tmdbId:d.imdbId, .name } ]
}
ORDER BY n.imdbRating DESC LIMIT 4
RETURN collect(n)
注：collect会打断流式传输，必须把所有n算出来在返回给客户端
1.18.2列表推导式
[ pattern | expression ] : 左边是match 右边是指定每一项的结果
MATCH (n:Movie)
WHERE n.imdbRating IS NOT NULL
WITH n {
.title,
.imdbRating,
actors: [ (n)<-[:ACTED_IN]-(p) | p { .imdbId, .name } ],
genres: [ (n)-[:IN_GENRE]->(g) | g {.name} ]
}
ORDER BY n.imdbRating DESC
LIMIT 10
RETURN collect(n)
1.18.3管道
将5个m用作下一步的match:
WITH 'Tom Hanks' AS theActor
MATCH (p:Person)-[:ACTED_IN]->(m:Movie)
WHERE p.name = theActor
WITH m LIMIT 5
MATCH (d:Person)-[:DIRECTED]->(m)
RETURN d.name AS director,
m.title AS movies
1.18.4列表展开与管道
UNWIND
返回的行将是电影标题和语言属性（重复多行）以及语言值:
MATCH (m:Movie)-[:ACTED_IN]-(a:Actor)
WHERE a.name = 'Tom Hanks'
UNWIND m.languages AS lang
RETURN m.title AS movie,
m.languages AS languages,
lang AS language
返回包含每种语言名称以及该语言的最多 10 部电影标题列表：
MATCH (m:Movie)
UNWIND m.languages AS lang
WITH m, trim(lang) AS language
// this automatically, makes the language distinct because it's a grouping key
WITH language, collect(m.title) AS movies
RETURN language, movies[0..10]
1.19减少内存
1.19.1子查询
MATCH (m:Movie)
CALL {
WITH m
MATCH (m)<-[r:RATED]-(u:User)
WHERE r.rating = 5
RETURN count(u) AS numReviews
}
RETURN m.title, numReviews
ORDER BY numReviews DESC
上述查询等效于：
for each m:
进入子查询
只处理这一部电影
立即算 count
返回一个数字
避免直接查询出现以下问题：
先展开所有电影×评分
再整体聚合
注：子查询必须通过 WITH 显式接收外层变量
1.19.2合并查询结果
MATCH (m:Movie) WHERE m.year = 2000
RETURN {type:"movies", theMovies: collect(m.title)} AS data
UNION ALL
MATCH (a:Actor) WHERE a.born.year > 2000
RETURN { type:"actors", theActors: collect(DISTINCT a.name)} AS data
等价于：
return [
{
data:{
type:"movies",
theMovies:[...]
}
},
{
data:{
type:"actors",
theActors:[...]
}
}
]
注:UNION ALL不会去重，但是一般也不推荐直接用UNION，因为会吃性能和内存
配合子查询使用：
MATCH (p:Person)
WITH p LIMIT 100
CALL {
WITH p
OPTIONAL MATCH (p)-[:ACTED_IN]->(m:Movie)
RETURN m.title + ": " + "Actor" AS work
UNION
WITH p
OPTIONAL MATCH (p)-[:DIRECTED]->(m:Movie)
RETURN m.title+ ": " + "Director" AS work
}
RETURN p.name, collect(work)
UNION使得可以同时输出两种类型work
1.20参数
1.20.1单参数
:param number: 10 // 此形式会自动转为浮点数
:param number=> 10 // 此形式会使用整型
1.20.2多参数
:params {actorName: 'Tom Cruise', movieName: 'Top Gun'}
追加参数：
:param number=> 10
1.20.3查看及删除参数
查看参数：
:params
删除参数：
:params {}
2.写入
2.1创建节点
创建单个：
MERGE (p:Person {name: 'Michael Caine'})
CREATE (p:Person {name: 'Michael Caine'})
创建多个：
MERGE (p:Person {name: 'Katie Holmes'})
MERGE (m:Movie {title: 'The Dark Knight'})
RETURN p, m
CREATE (p:Person {name: 'Katie Holmes'})
CREATE (m:Movie {title: 'The Dark Knight'})
RETURN p, m
注：CREATE和MERGE区别是CREATE会永远新建一个新节点，但是MERGE会查看是否有重复节点 重复就会复用（创建时属性完全一致才行 否则也会新建节点的）
2.2创建关系
先查找节点并创建关系：
MATCH (p:Person {name: 'Michael Caine'})
MATCH (m:Movie {title: 'The Dark Knight'})
MERGE (p)-[:ACTED_IN]->(m)
创建节点并同时设置关系：
MERGE (p:Person {name: 'Chadwick Boseman'})
MERGE (m:Movie {title: 'Black Panther'})
MERGE (p)-[:ACTED_IN]-(m)
MERGE (p:Person {name: 'Emily Blunt'})-[:ACTED_IN]->(m:Movie {title: 'A Quiet Place'})
RETURN p, m
注：若不指定关系的方向，默认情况是从左到右
2.3设置关系属性
MATCH (p:Person {name: 'Michael Caine'})
MERGE (m:Movie {title: 'Batman Begins'})
MERGE (p)-[:ACTED_IN {roles: ['Alfred Penny']}]->(m)
RETURN p,m
通过apoc程序添加关系：
MATCH (n:Actor)-[:ACTED_IN]->(m:Movie)
CALL apoc.merge.relationship(n,
'ACTED_IN_' + left(m.released,4),
{},
{},
m ,
{}
) YIELD rel
RETURN count(*) AS `Number of relationships merged`;
建立新的关系ACTED_IN_xxx，用于表示演员在什么年份参演了某部电影，防止在直接查询过程中遍历全部电影
2.4属性支持的类型
| 分类 | 类型 | 是否支持 | 示例 | 说明 |
|---|---|---|---|---|
| 数值 | Integer | ✅ | {age: 30} |
整数 |
| 数值 | Float | ✅ | {price: 19.9} |
浮点数 |
| 字符串 | String | ✅ | {name: 'Alice'} |
最常用 |
| 布尔 | Boolean | ✅ | {active: true} |
true/false |
| 时间 | Date | ✅ | {d: date('2025-01-01')} |
日期 |
| 时间 | Datetime | ✅ | {t: datetime()} |
含时区 |
| 时间 | LocalDateTime | ✅ | {t: localdatetime()} |
无时区 |
| 时间 | Time | ✅ | {t: time()} |
带时区时间 |
| 时间 | LocalTime | ✅ | {t: localtime()} |
本地时间 |
| 时间 | Duration | ✅ | {dur: duration('P1D')} |
时长 |
| 空间 | Point | ✅ | {loc: point({latitude:40.7, longitude:-74})} |
地理坐标 |
| 数组 | 同类型数组 | ✅ | {tags:['a','b']} |
必须同类型 |
| 数组 | 数值数组 | ✅ | {nums:[1,2,3]} |
支持 |
| 数组 | 布尔数组 | ✅ | {flags:[true,false]} |
支持 |
| 数组 | 嵌套数组 | ❌ | {bad:[[1],[2]]} |
不允许 |
| 数组 | 混合类型数组 | ❌ | {bad:[1,'a']} |
不允许 |
| 复杂 | Map/Object | ❌ | {info:{age:18}} |
不允许 |
| 复杂 | JSON | ❌ | {json:{...}} |
不允许 |
| 复杂 | Node | ❌ | {u:node} |
不允许 |
| 复杂 | Relationship | ❌ | {r:rel} |
不允许 |
2.5设置属性
支持同时设置多个
MATCH (p:Person)-[r:ACTED_IN]->(m:Movie)
WHERE p.name = 'Michael Caine' AND m.title = 'The Dark Knight'
SET r.roles = ['Alfred Penny'], m.released = 2008
RETURN p, r, m
在创建/匹配成功阶段执行set:
// Find or create a person with this name
MERGE (p:Person {name: 'McKenna Grace'})
// Only set the `createdAt` property if the node is created during this query
ON CREATE SET p.createdAt = datetime()
// Only set the `updatedAt` property if the node was created previously
ON MATCH SET p.updatedAt = datetime()
// Set the `born` property regardless
SET p.born = 2006
RETURN p
2.6删除属性
MATCH (p:Person)-[r:ACTED_IN]->(m:Movie)
WHERE p.name = 'Michael Caine' AND m.title = 'The Dark Knight'
REMOVE r.roles
RETURN p, r, m
通过设置为null删除
MATCH (p:Person)
WHERE p.name = 'Gene Hackman'
SET p.born = null
RETURN p
注：绝对不能删除用作节点主键的属性。
2.7删除节点及关系
删除节点：
MATCH (p:Person {name: 'Jane Doe'})
DELETE p
删除节点和关系：
MATCH (p:Person {name: 'Jane Doe'})-[r:ACTED_IN]->(m:Movie {title: 'The Matrix'})
DELETE r
RETURN p, m
注：必须先删除关系再删除节点，单独删除节点会报错
删除节点同时删除与之相关关系：
MATCH (p:Person {name: 'Jane Doe'})
DETACH DELETE p
2.8整库删除节点及关系
谨慎使用！！
MATCH (n)
DETACH DELETE n
2.9添加和删除标签
添加标签：
MATCH (p:Person {name: 'Jane Doe'})
SET p:Developer
RETURN p
删除标签：
MATCH (p:Person {name: 'Jane Doe'})
REMOVE p:Developer
RETURN p
2.10列出全部标签
CALL db.labels()
2.11批量添加标签
为存在某个关系的标签添加额外标签：
MATCH (p:Person)
WHERE exists ((p)-[:ACTED_IN]-())
SET p:Actor
2.12将属性值重构为节点
MATCH (m:Movie)
UNWIND m.languages AS language
MERGE (l:Language {name:language})
MERGE (m)-[:IN_LANGUAGE]->(l)
SET m.languages = null
这段代码遍历所有电影节点，并为找到的每种语言创建一个语言节点，然后使用IN_LANGUAGE关系在**电影节点和语言节点之间创建关系。
等价于js伪代码：
for (const m of movies) {
for (const language of m.languages) {
MERGE (l:Language {name:language})
MERGE (m)-[:IN_LANGUAGE]->(l)
}
}
